Air quality controllers
Order numbers
GS 40.01 knxCO2- air quality sensor & controller
GS 40.01 knx
CO2- air quality sensor & controller
GS 41.01 knx
CO2- air quality sensor & controller with manual set-point temperature adjustment ± 3°C
Air quality sensors & controllers GS 40.01 knx / GS 41.01 knx
Order information
| EAN | Art. No. | |
| GS 40.01 knx white | 4022709242983 | 24298 |
| GS 41.01 knx white | 4022709242990 | 24299 |
| GS 40.01 knx black | 4022709243065 | 24306 |
| GS 41.01 knx black | 4022709243072 | 24307 |
Overview
- Detection of air quality
(CO2-concentration, rel. humidity, temperature) - CO2-sensor (Measuring range 390...5.000 ppm air pressure compensated)
- CO2-value is atmospheric pressure compensated
- Sensors for CO2-, temperature, humidity and atmospheric pressure measurement
- Temperature sensor (Measuring range 0°...+50° C)
- Humidity sensor (Measuring range 0...100% rel. humidity)
- Humidity comparator function
- Clearly structured ETS
- Easy installation and mounting
- Modern and planar design
- Wall mounting [80 mm]
- Party function
- Extension of the value range of setpoints
- Temperature control with up to 4 sensor values possible
- Additional VAV controller
- and much more
- Additionally at GS 41.01 knx: manual adjustment of set-point temperature via touch panel (adjustment range ± 3 °, increment 0,5 °)
