| Supply voltage |
230 V, 50–60 Hz |
| Power consumption (real power) |
0,45–1,25 W (depending on the switching status) |
| Channel (potential-free) |
Change-over, contact gap < 3 mm (µ) |
| Contact material |
AgSnO2 |
Switching capacity
resitive load:
inductive load: |
16 A / 250 V~ at cosϕ=1
6 A bei at cosϕ=0,6 |
| Min. switching power |
1.000 mW (10 V / 10 mA) |
| Max. starting current |
50 A max. 20 ms |
| Filament Lamp, Halogen Lamp |
2.000 W |
| Fluorescent Lamp uncompensated |
1.000 W |
| Fluorescent Lamp series compensated |
1.000 W |
| Fluorescent Lamp parallel compensated |
550 W |
| CFL |
200 W |
LED (230 V~)
(LED lamps > 5W) |
200W |
| Switching functions |
Lux; Night OFF; Night ON |
| Adjustable lux threshold |
1–50.000 Lux |
| Adjustable delay times |
00:01 bis 09:59 mm:ss |
| Adjustable light-hysteresis |
1–200 Lux |
| Memory locations |
2 |
| Time base |
Quartz |
| Quartz accuracy (at 20 °C) |
≤ ±0,5 sec./day (Quartz accuracy optimized for typical ambient conditions) |
| Power back-up (at 20 °C) |
approx. 10 years (depends on the Lithium-battery life) |
| Program security |
unlimited |
| Display |
iluminated LCD-display |
| Permitted ambient temperature |
Sensor unit –30…+50 °C
Control unit –30…+50 °C |
| Housing |
self-extinguishing thermoplastic |
| Dimensions |
45 x 35 x 58 mm |
| Mounting |
35 mm DIN-rail |
| Type of connection |
Screw terminals (pull-up type) |
| Type of protection |
Sensor unit IP 54 to DIN EN 60529
Control unit IP 20 to DIN EN 60529 |
| Class of protection |
II when installed according to regulations |
| Minimum requirement |
Android: from Version 4.4
iOS: from Version 13.2.3, Modell: from IPhone7 |
Accessories
(free download) |
Programmable with smartphone via NFC:
App - Save`n Carry |
