Codice ordinativo

EA 16.11 pro4

Bluetooth-Steuerung
Schaltuhr Woche
Schaltuhr Astro
Uhrenthermostat
Hygrostat
Remotefunktion

Accessories

Multifunctional device (remote-controllable)
Universal control
- Time switch week
- Time switch astro
- Clock thermostat (with LS 20.00 pro4) or
- Hygrostat (with LS 20.00 pro4)
1 output channel 230 V~
1 input 230 V~ for push-buttons or switches
Switching capacity 5 A in total
Fully automatic daylight saving time
approx. 10 years reserve
Bluetooth Mesh Technology
Programmable and controllable via app (iOS and Android)
Remote control possible via gateway
Switching program can be deactivated via app
Up to 75 m range
Protection against overheat
Flush-mounted fitting
Compact housing

1 output channels 230 V~
100 memory locations
Minimum interval 1 min.
Extra switching times ON, OFF and pulse by date and time
Permanent by date and time / holiday function
Pulse length Pulse function (switching time)
00:01 up to 59:59 mm:ss
Output functionality adjustable and depending on input signal:
- Change function between ON and OFF
- Timer function (e.g. staircase lighting, ventilation)
Option advance warning (application staircase lighting timer)
3 modes of operation: automatic, manual, random function

1 output channels 230 V~
100 memory locations
Minimum interval 1 min.
Offset function = for each switching time a difference (±90 min.) to the Astro time can be programmed
Permanent by date and time / holiday function
Output functionality adjustable and depending on input signal:
- Change function between ON and OFF
- Timer function (e.g. staircase lighting, ventilation)
Option advance warning (application staircase lighting timer)
2 modes of operation: automatic and manual

Hugo Müller GmbH & Co KG

Tel.: +49 (0) 7720 80 836

	EAN	Art. No.
EA 16.11 pro4	4022709240842	24084

Supply voltage	230 V, 50-60 Hz
Power consumption (real power)	<0,15 - 0,375 W (depending on the switching status)
Channels (potential of supply voltage)	1x output normally open
Switching capacity in total ohmic load	Time switch: 5 A at cosφ=1 Thermostat: 3 A at cosφ=1 Hygrostat: 4 A at cosφ=1
Transmission type	Bluetooth LE Range max. 75 m
Inputs	1x inputs 230 V~
Input function	push-button / switch Time switch: change ON / OFF or timer
Time base	Quartz
Quartz accuracy	≤ ±0,5 Sec./day (Quartz accuracy optimized for typical ambient conditions)
Power back-up (at 20°C)	approx. 10 years (depends on the Lithium-battery life)
Permitted ambient temperature	-30° ... +45°C
Housing	self-extinguishing thermoplastic
Dimensions	38 x 38 x 10 mm
Mounting	Flush-mounting (preferrably combined with hollow-wall box)
Type of connection	With litz wires
Class of protection	II when installed according to regulations
Mode of operation (DIN EN 60730-1) (DIN EN 60730-2-7)	1 BSTU
Degree of contamination (DIN EN 60730-1)	2
Rated surge voltage (DIN EN 60730-1)	4 kV
Minimum requirement	Android Version 7.0 iOS 11.0 Bluetooth 4.0
Accessory (free download)	Programmable and controllable with smartphone via Bluetooth: App - mi.puck
