Bestelnummers

TS 30.00 pro

Raumtemperatur-
sensor (0-10 V)

Accessories

Hugo Müller GmbH & Co KG

Tel.: +49 (0) 7720 80 836
Fax: +49 (0) 7720 80 83 88

	EAN	Art. No.
TS 30.00 pro	4022709243829	24382

Supply voltage	24 V ACDC
Sensors	Temperature
Measuring range temperature	0°...+50° C
Outputs	1x analogue outputs ( 0-10 V )
Analogue measurement output	Temperature: 0-50° C
Permitted ambient temperature	0°...+50° C
Housing	self-extinguishing thermoplastic
Dimensions	80,5 x 80,5 x 17 mm
Housing color	studio white (similar to RAL 9016) Specific colors on request
Mounting	Wall mounting (preferrably combined with flush-mounting box)
Type of connection	Push-in connector
Type of protection	IP 20 (DIN EN 60529)
Class of protection	III when installed according to regulations
